5~24Vdc旋轉編碼器
NT$3205
Part No:
51058
Product No:
E6B2-CWZ6C-360P/R-2M
品牌:
OMRON
說明:
技術文件:
包裝單位:
1 PC
產品特性
- 特性
OMRON-E6B2
Features
●A wide operating voltage range of 5 to 24 VDC (Open-collector Models).
●Resolution of 2,000 pulses/revolution in 40-mm housing.
●Phase Z can be adjusted with ease using the origin indicating function.
●A large load of 30 N in the radial direction and 20 N in the thrust direction is permitted.
●The load short-circuit and reversed connection protecting circuit assures highly reliable operation (except for line-driver outputs).
